HP 8360 L Series User Manual

Fltness Menu
1601 Equodistont
Point Arroy
Accessible Only
From o Computer
User Flatness Correction Arroy
1601 Points of Internal
Calibration Data
1601 Points
for ALC
Figure F-3. The Sources of ALC Calibration Correction Data
If the correction frequency span is only a subset of the start/stop
frequency span set on the source, no corrections are applied to the
portion of the sweep that is outside the correction frequency span.
The following example illustrates how the data is distributed within
the user flatness correction array.
Assume that the swept CW generator is set to sweep from 2 to
18 GHz, but you only enter user flatness correction data from
14 to 18 GHz. Linear interpolation occurs between the correction
entries to provide the 401 points required for the 14 to 18 GHz
portion of the array. No corrections are applied to the 2 to
13.99 GHz portion of the array. Refer to Figure F-4.
Point
Number
--+
0
1200
1600
No Corrections Applied
401 Points
of Doto
Frequency --) 2GHz
14GHz
18GHz
1st Cow. Freq.
Figure F-4.
Array Configuration when the Correction Data Frequency Span
is a Subset of the Swept CW Generator Frequency Span
Number of points interpolated between correction entries is
calculated as follows:
freq. span between correction entries
stop frequency - start frequency
I
1600 - 1 = Number of pts
When correction frequencies are arbitrarily spaced, the number of
interpolated points varies.
F-8 Operating and Programming Reference
