Figure 3-2. Rear Panel HP-IB Switch
HP-IB Address
In certain applications, the swept CW generator acts as a controller
Selection
for a power meter and a printer. Because of this, the address menu
provides access not only to the swept CW generator’s HP-IB address,
but also to the address at which the swept CW generator expects to
see a power meter, and the address at which the swept CW generator
expects to see a printer. (See Table 3-3 for factory-set addresses.)
Table 3-3. Factory-Set HP-IB Addresses
Instrument HP-IB Address
(Decimal)
Swept CW Generator
19
Power Meter
13
Printer
01
Installation 3-7
