Disp Status
Delta Mkr Ref
Function Group
Menu Map
Description
Programming Codes
See Also
MARKER
3
This
softkey
displays the five markers available as the delta marker
reference. The delta marker frequency is calculated using the
equation:
f($,=fm-fmraf
where
f,
is the frequency of the active marker and
fmref
is the
frequency of the reference marker.
SCPI: MARKer:REFerenc <marker number>
Analyzer:
MD1 function on,
MD0
function off.
Delta Marker
“Marker Operation” in Chapter 1
“Programming Typical Measurements” in Chapter 1
Disp Status
Function Group
SYSTEM
Menu Map
8
Description
This softkey causes the status of various features to be displayed.
For example, this is what the swept CW generator displays as its
status after a factory preset:
Pls=Off
Lvl=Int
RF
Slp=Off
AM=Off
ALC=On
Pwr
Swp=Off
FM=Off
UsrCorr=Off
SwpMode=Swept
Altn=Off SwpTrig=Auto AutoCal=None
This key is useful when checking the current operation state of
the swept CW generator. The following is a listing of the various
mnemonics used to indicate status.
Operating and Programming Reference D-5
