Local
Operator’s
Check
Description
The preliminary check provides assurance that most of the internal
functions of the swept CW generator are working. The main check
provides a general check of the overall functions of the swept CW
generator. No external equipment is needed.
Preliminary Check
Each time the swept CW generator is turned on the swept CW
generator performs a series of self tests on the internal CPU, power
supplies, and front panel. When the self test is complete, the swept
CW generator returns to the same functional configuration that
it was in prior to power off. When the
[PRESETj
key is engaged, the
swept CW generator returns to the factory or user preset functional
configuration.
1. Turn the swept CW generator on. Note the functional
configuration.
2. Turn the swept CW generator off. Verify that the amber
STANDBY LED is on.
3. Turn the swept CW generator on. Verify that the amber
STANDBY LED is off, and that the green POWER ON LED is
on.
a. Check the display, a cursor will appear in the upper left corner
followed by the HP-IB language, HP-IB address, and the date
code of the firmware installed in the swept CW generator.
b. The display will now indicate the functional configuration
noted in step 1.
c. Check the fan, it should be turning.
4-2 Operator’s Check/Routine Maintenance
