Pulse
C?n/UffScalar
Pt Trig Menu
Function Group
FREQUENCY
Menu Map
2
Description
This
softkey
accesses the list mode point trigger softkeys.
List Mode Pt Trig Auto
Automatically steps the swept CW
generator to the next point in the
frequency list.
List Mode Pt Trig Bus Steps the swept CW generator to
the next point in the frequency list
when an HP-IB trigger is received.
List Mode Pt Trig Ext
Steps the swept CW generator to
the next point in the frequency list
when an external hardware trigger
is received.
Programming Codes
SCPI: NONE
Analyzer: NONE
See Also
Softkeys listed above, List Menu
Pulse
On/Off
Scalar
Function Group
Menu Map
Description
4
This
softkey
activates pulse modulation mode, and sets the internal
pulse generator to produce 27.778 kHz square wave pulses
(18 ps pulse width, 36 ps pulse period). The rise and fall times of
the RF envelope are approximately 2 ps. These pulses allow proper
operation with HP scalar network analyzers in ac detection mode.
An asterisk next to the key label indicates that this feature is active.
Operating and Programming Reference P-15
