CONNECTORS
RF Output Connector
The swept CW generator is equipped with a precision 3.5 mm male
connector (2.4 mm male connector on 40 GHz models). The output
impedance, SWR, and other electrical characteristics are listed in
“Specifications.” When making connections, carefully align the center
conductor elements, then rotate the knurled barrel while the mating
component remains still. Tighten until firm contact is made.
Take care when working with either of these connectors. If this
connector is mechanically degraded in any way, high frequency losses
occur. Refer to Application Note 326, Connector Cure, for more
information.
Function Group
SWEEP
Menu Map
7
Description
This
hardkey
initiates continuous sweep-retrace cycling of the swept
CW generator. The sweep is initiated by one of the trigger functions,
while the sweep speed is controlled by the sweep time function.
The green LED located above this key lights when the swept CW
generator is performing a list, step, or analog sweep.
The LED is off during all of the following: retrace, band crossings,
phase locking at the start frequency of each new sweep and during
manual sweeps.
Programming Codes
SCPI:
1NITiate:CONTinuous
ON11
Analyzer:
Sl
See Also
Manual Sweep,
(SINGLE)
“Continuous, Single, and Manual Sweep Operation” in Chapter 1
“Programming Typical Measurements” in Chapter 1
C-10 Operating and Programming Reference
