Peak RF Once
Function Group
Menu Map
Description
Programming Codes
See Also
POWER, USER CAL
5,
9
This softkey appears in two locations: the POWER Tracking Menu
and the USER CAL Tracking Menu. The operation is the same in
both locations.
This softkey causes an instantaneous, one-time execution of the
peaking function when the swept CW generator is in the CW or
manual sweep mode. It aligns the output filter (SYTM) so that its
passband
is centered on the RF output.
SCPI: CALibration:PEAKing[:EXECute]
Analyzer: SHAK
Auto Tracking,
Peak RF Always, Tracking Menu
“Optimizing Swept CW Generator Performance” in Chapter 1
[POWER
LEVEL]
Function Group
POWER
Menu Map
NONE
Description
This
hardkey
lets you control the output power level of the swept
CW generator. The swept CW generator has different power leveling
modes and leveling points, and as such, the [POWER LEVEL key
controls different aspects of the power level (ALC) system.
The following is an explanation of power level operation in the
different ALC system configurations.
In Normal, Internal, the (POWER LEVEL) key controls the output power
level of the swept CW generator directly. The attenuator (if present)
is controlled together with the complete range of the ALC system
(+25
to -20
dBm).
P-2 Operating and Programming Reference
