RF
Output
Output Power
Maximum Leveled
3
Standard
HP 83623L
+15
HP 8363OL
Output Frequencies < 20 GHz
Output Frequencies
2
20 GHz
HP
83640L
+13
+10
Output Frequencies < 26.5 GHz
+10
Output Frequencies > 26.5 GHz
+6
HP 8365OL
Output Frequencies < 26.5 GHz
+10
Output Frequencies
2
26.5 GHz and < 40 GHz
+5
Output Frequencies
)
40 GHz
+2.5
With attenuator (Option 001): Minimum
settable
output power is
-110 dBm. Maximum leveled output power is reduced by 1.5 dB to
20 GHz, 2.0 dB above 20 GHz, and 2.5 dB above 40 GHz.
Minimum Settable
Standard: -20
dBm
Option 001: -110
dBm
Resolution: 0.02 dB
Switching Time: (without attenuator change): 10 ms, typical
Temperature Stability: 0.01
dB/“C,
typical
Typical Maxium Available Power
5
I I
I
I
I
I
01
I
1
I I
I
I I 1
0
I0
20
30
40
50
Frequency
(GHz)
uo711
3
Specification applies over the 0 to 35
‘C
temperature range (0 to 25
‘C
for output
frequencies > 20 GHz). Maximum leveled output power over the 35 to 55
‘C
temperature range typically degrades by less than 2 dB.
