HP P2000 G3 MSA System CLI Reference Guide 275
Remote link information:
Connected Ports
• For a remote primary or secondary volume, this field shows the IDs of up to two hosts ports in the
local system that are connected to the remote system. If two ports are connected but only one is
shown, this indicates that a problem is preventing half the available bandwidth from being used.
• For a local primary or secondary volume, this field shows N/A.
Remote Address
The address of each host port in the remote system through which the volume is accessible.
Example Show information about all replication volumes:
# show replication-volumes
Name Serial Number Status Status-Reason Monitor Location
Primary-Volume Primary-Volume-Serial Primary-Volume-Status MaxQueue
MaxRetryTime On Error Link Type On Collision Monitor Interval
Priority Connection Status Connection Time
-----------------------------------------------------------------------------
vd01_v001 SN Online N/A OK Remote
vd01_v001 SN Online 32
1800 Retry iSCSI Oldest 300
Medium Online 2018-01-18 10:04:00
Connected Ports Remote Address
--------------------------------------------------------------
A1 IP=10.134.9.46:3260
IP=10.134.9.47:3260
IP=10.134.9.48:3260
A1 IP=10.134.9.49:3260
rvd01_v001 SN Online N/A OK Local
vd01_v001 SN Online 32
1800 Retry iSCSI Oldest 300
Medium Not Attempted N/A
Connected Ports Remote Address
--------------------------------------------------------------
N/A IP=10.134.9.40:3260
N/A IP=10.134.9.41:3260
N/A IP=10.134.9.42:3260
N/A IP=10.134.9.43:3260
Success: Command completed successfully. (2012-01-18 15:16:46)
Basetypes • replication-volume
• status
See also • set replication-volume-parameters
• show replication-sets
