LED Indicators, Switches, and Jumpers
Resetting System Configuration Settings
It may be necessary at some time to clear and reset system configuration settings.
When the system configuration switch position 6 is set to the On position, the server
is prepared to erase all system configuration settings from both CMOS and NVRAM.
CAUTION: Clearing nonvolatile RAM (NVRAM) deletes the system configuration.
Refer to Chapter 5, “Server Configuration and Utilities,” for instructions on
configuring the server.
To reset system configuration settings:
1. Power down the server.
2. Set the system configuration switch position 6 to the On position.
3. Power up the server.
All configuration settings are now erased and all server operations halt.
4. Power down the server, when prompted during POST.
5. Reset the position 6 switch to the default Off position.
6. Power up the server.
7. Reset all system configuration settings by pressing the F9 key (or the F8 key if
you are using an ATA model) to run the ROM-Based Setup Utility (RBSU).
Refer to Chapter 5, “Server Configuration and Utilities,” or the HP ROM-Based
Setup Utility User Guide, for more information on RBSU.
E-10 HP ProLiant ML310 Server Setup and Installation Guide
HP CONFIDENTIAL
Writer: Ted Weiman File Name: l-appe.doc
Codename: Son of Beast Part Number: 274431-002 Last Saved On: 11/22/02 2:10 PM
