HPE FlexNetwork MSR Series Guide

151
Produ
ct
numbe
r
Description Cable Appearance
Applicable
models
JD512A
JD927A
HPE X260 8E1
BNC 75 ohm 3m
Router Cable
HPE CAB-75ohm
8E1-3m-BNC-IM
A
8-port E1
75-ohm cable
1 × D68 < ---- > 16 × BNC
MIM-8E1
MIM-8E1-F
MIM-IMA-8E
1
FIC-8E1
FIC-8E1-F
FIC-IMA-8E1
HMIM-8E1
JH294A
HPE X260 E1
RJ45 to 2xBNC
75ohm 3m
Router Cable
1-port E1
75-ohm RJ-45
cable
HMIM-8E1T1
HMIM-8E1T1
-F
SIC-1VE1T1
-
75-ohm
adapter cable
1 × BNC < ---- > 1 × BNC
Use as
needed
-
Coaxial
connector
1 × BNC < ---- > 1 × BNC
Use as
needed
JD511A
HPE X260 E1
RJ45 BNC
75-120 ohm
Conversion
Router Cable
Impedance
converter
2 × BNC < ---- > 1 × RJ45
Use as
needed
Dual inline package switch
E1/E1-F/VE1 interface module provides a dual inline package (DIP) switch. The DIP switch setting
defines the interface impedance and the grounding method.
