152
Table 238 DIP switch-to-interface map
DIP switch
E1 interface
Applicable models
S1 Interface 0
MIM-2E1
MIM-4E1
MIM-4E1-F
FIC-2E1
FIC-4E1
FIC-4E1-F
HMIM-2E1
HMIM-4E1
HMIM-4E1-F
SIC-1VE1
MIM-1VE1
MIM-2VE1
FIC-1VE1
FIC-2VE1
HMIM-1VE1
HMIM-2VE1
S2 Interface1
MIM-2E1
MIM-4E1
MIM-4E1-F
FIC-2E1
FIC-4E1
FIC-4E1-F
HMIM-2E1
HMIM-4E1
HMIM-4E1-F
MIM-2VE1
FIC-2VE1
HMIM-2VE1
S3 Interface2
MIM-4E1
MIM-4E1-F
FIC-4E1-F
HMIM-4E1
HMIM-4E1-F
S4 Interface3
MIM-4E1
MIM-4E1-F
FIC-4E1-F
HMIM-4E1
HMIM-4E1-F
By default, all DIP switches are On, and the E1 interface impedance is 70 ohms, as shown in the
following figure:
