Figure 4-115 Securing a cap (900 mm wide indoor unit used as an example)
Step 3 Secure the cap front panel to the frame, and adjust the angle of the front panel
blade.
● During the installation, grasp the panel frame instead of the blade to move the
panel to avoid blade deformation.
● The cap should be well sealed to the smart cooling product to ensure good
sealing performance in-between.
NetCol8000-A(045, 055, 060, 090, 120) In-room Air
Cooled Smart Cooling Product
User Manual 4 System Installation
Issue 05 (2020-10-10) Copyright © Huawei Technologies Co., Ltd. 146
