Item Specifications
Maximum capacity per DIMM (GB) 128
Maximum total memory capacity (GB) 4096
Maximum total memory capacity at
maximum operating speed (GB)
2048
Maximum operating
speed (MT/s)
One DIMM per
channel
2933
Two DIMMs per
channel
2666
5.8.2 Memory Subsystem Architecture
The TaiShan 2280 V2 provides 32 DDR4 DIMM slots. Each CPU supports eight channels.
Table 5-2 lists channels for each CPU.
Table 5-2 Channels
CPU
Channel DIMM
CPU 1 TB_A DIMM060(G)
DIMM061(O)
TB_B DIMM020(C)
DIMM021(K)
TB_C DIMM040(E)
DIMM041(M)
TB_D DIMM000(A)
DIMM001(I)
TA_A DIMM030(D)
DIMM031(L)
TA_B DIMM070(H)
DIMM071(P)
TA_C DIMM010(B)
DIMM011(J)
TA_D DIMM050(F)
DIMM051(N)
CPU 2 TB_A DIMM160(G)
TaiShan 2280 V2 Server
User Guide
5 Optional Part Installation
Issue 01 (2019-07-01) Copyright © Huawei Technologies Co., Ltd. 97
