Huawei TaiShan 2280 V2 User Manual

7.1 Internal Cabling for a Server with 12 x 3.5-inch Drives in Expander Mode
7.2 Internal Cabling for a Server with 12 x 3.5-inch Drives in Pass-Through Mode
7.3 Internal Cabling for a Server with 25 x 2.5-inch Drives in Expander Mode
7.4 Internal Cabling for a Server with 8 x 2.5-inch SAS/SATA Drives and 12 x 2.5-inch
NVMe SSDs
7.5 Internal Cabling for a Server with I/O Module 3
7.1 Internal Cabling for a Server with 12 x 3.5-inch Drives
in Expander Mode
Left and Right Mounting Ear Cabling
Figure 7-2 Left and right mounting ear cabling
Table 7-2 Left and right mounting ear cabling
No.
Description Huawei Part
Number
1 Signal cable for connecting the mainboard (J6030) to the
right mounting ear plate
04052311
2 Signal cable for connecting the mainboard (J92) to the left
mounting ear plate
04080650
TaiShan 2280 V2 Server
User Guide
7 Internal Cabling
Issue 01 (2019-07-01) Copyright © Huawei Technologies Co., Ltd. 111
