Item Specifications
Security
l Administrator password
l (Optional) Front bezel
NOTE
The front bezel is installed on the front panel and comes with a security lock to
prevent unauthorized operations on drives.
Graphics card The mainboard integrates an SM750 graphics card, providing 32 MB
memory and supporting a maximum resolution of 1920 x 1200 at 60 Hz
with 16 M colors.
NOTE
l The maximum resolution 1920 x 1200 is supported only after the video card
driver that corresponds to the server OS version is installed. Otherwise, only
the default resolution of the OS is supported.
l If both the front and rear VGA ports are connected to monitors, only the
monitor connected to the front VGA port is available.
13.2 Environmental Specifications
Table 13-2 Environmental specifications
Category
Specifications
Temperature
l Operating temperature: 5°C to 40°C (41°F to 104°F)
(ASHRAE Classes A2 and A3 compliant)
l Storage temperature: –40°C to +65°C (–40°F to +149°F)
l Long-term storage temperature: 21°C to 27°C (69.8°F to
80.6°F)
l Maximum temperature change rate: 20°C/h (36°F/h)
NOTE
The highest operating temperature varies depending on the
configuration. For details, see Table 13-3.
Relative humidity (RH,
non-condensing)
l Operating humidity: 8% to 90%
l Storage humidity: 5% to 95%
l Long-term storage humidity: 30% to 69%
l Maximum change rate: 20%/h
Air volume ≥ 204 cubic feet per minute (CFM)
TaiShan 2280 V2 Server
User Guide
13 Product Specifications
Issue 01 (2019-07-01) Copyright © Huawei Technologies Co., Ltd. 142
