No. Description
4 Year and month (two characters).
l The first character indicates the year. Digits 1 to 9 indicate 2001 to
2009, letters A to H indicate 2010 to 2017, letters J to N indicate 2018
to 2022, and letters P to Y indicate 2023 to 2032.
NOTE
The years from 2010 are represented by upper-case letters excluding I, O, and
Z because the three letters are similar to digits 1, 0, and 2.
l The second character indicates the month. Digits 1 to 9 indicate
January to September, and letters A to C indicate October to
December.
5 Serial number (six characters).
6 RoHS compliance (one character). Y indicates environment-friendly
processing.
7 Internal model, that is, product name.
2.2 Front Panel Indicators and Buttons
l Figure 2-5 shows the indicators and buttons on the front panel of a server with 12 x 3.5-
inch drives.
Figure 2-5 Indicators and buttons on the front panel of a server with 12 x 3.5-inch drives
1
UID button/indicator 2 Health indicator
3 Power button/indicator 4 Fault diagnostic LED
5 FlexIO presence indicators (1 and 2) - -
l Figure 2-6 shows the indicators and buttons on the front panel of a server with 25 x 2.5-
inch drives.
TaiShan 2280 V2 Server
User Guide
2 Components
Issue 01 (2019-07-01) Copyright © Huawei Technologies Co., Ltd. 5
