Table 2-1 Description of ports on the front panel
Port Type Description
USB port USB 3.0 The USB ports allow USB
devices to be connected to the
server.
NOTE
Before connecting an external USB
device, check that the USB device
functions properly. A server may
operate abnormally if an abnormal
USB device is connected.
VGA port DB15 The VGA port is connected to a
terminal, such as a monitor or
KVM.
SN
The serial number (SN) on the label is a string that uniquely identifies a server. The SN is
required when you contact Huawei technical support.
Figure 2-4 shows the SN format.
Figure 2-4 SN example
Table 2-2 SN description
No.
Description
1 SN ID (two characters), which is 21.
2 Material identification code (eight characters), that is, processing code.
3 Vendor code (two characters). The value 10 indicates Huawei and other
values indicate outsourcing vendors.
TaiShan 2280 V2 Server
User Guide
2 Components
Issue 01 (2019-07-01) Copyright © Huawei Technologies Co., Ltd. 4
