Huawei TaiShan 2280 V2 User Manual

Table 13-3 Operating temperature limitations
Model Max. 30°C (86°F) Max. 35°C (95°F)
(ASHRAE Class
A2 Compliant)
Max. 40°C (104°F)
(ASHRAE Class
A3 Compliant)
EXP model with 12
x 3.5-inch drives
Supports all configurations.
l Does not support
64-core CPUs.
l Does not support
PCIe SSD cards
l Does not support
passive cooling
GPUs (including
DMINI cards).
l Does not support
rear drives
Pass-through model
with 12 x 3.5-inch
drives
Supports all configurations.
EXP model with 25
x 2.5-inch drives
Supports all configurations.
Server with 8 x 2.5-
inch SAS/SATA
drives and 12 x 2.5-
inch NVMe SSDs
Supports all configurations. Not supported
13.3 Physical Specifications
Physical Specifications
Table 13-4 Physical specifications
Item
Description
Dimensions (H
x W x D)
Chassis with 3.5-inch drives: 86.1 mm (2U) x 447 mm x 790 mm (3.39
in. x 17.60 in. x 31.10 in.)
Chassis with 2.5-inch drives: 86.1 mm (2U) x 447 mm x 790 mm (3.39
in. x 17.60 in. x 31.10 in.)
Installation
space
l Requirements for cabinet installation:
Cabinet compliant with the International Electrotechnical
Commission (IEC) 297 standard
– Cabinet width: 482.6 mm (19 in.)
– Cabinet depth: ≥ 1000 mm (39.37 in.)
l Requirements for guide rail installation:
– L-shaped guide rails: apply only to Huawei cabinets.
– Adjustable guide rails: apply to a cabinet with a distance of 543.5
mm to 848.5 mm (21.40 in. to 33.41 in.) between the front and
rear mounting bars.
TaiShan 2280 V2 Server
User Guide
13 Product Specifications
Issue 01 (2019-07-01) Copyright © Huawei Technologies Co., Ltd. 144
