Hypertherm ArcGlide Torch Height Control User Manual

ArcGlide THC Instruction Manual 4-9
MAINTENANCE
Basic flow for all ArcGlide operating states
Enter operating state.
First time in this
state?
Update motor drive and lifter
brake outputs.
Update CNC interface and
plasma supply outputs, front
panel status LEDS.
Set desired torch position.
ion
Reset state timer.
Not the first time in this state.
Error condition?
Change to new
state?
Error = this error.
Next state = error state.
Exit operating state
Next state = new state.
Next state =
this state
no
yes

Hypertherm ArcGlide Torch Height Control Specifications

General

Brand	Hypertherm
Model	ArcGlide Torch Height Control
Category	Cutter
Language	English
