Hypertherm XPR300 Replacement Part Procedures

Parts List
5
XPR300 Instruction Manual 809970 137
Part number Description Quantity
1 229793 Manifold: Gas input (no adapters) 1
2 104843 Manifold: Gas output (no adapters) 1
3 229844 Water regulator 1
4 006157 Check valve 4
Push-to-connect adapters
5 015905 1/8 inch NPT X 1/4 inch tube 1
6 015853 Elbow: 1/4 inch NPT X 5/16 inch tube 1
7 015876 1/4 inch NPT X 1/4 inch tube 1
8 015907 1/4 inch NPT X 3/8 inch tube 1
9 015909 Elbow: 3/8 inch NPT X 5/16 inch tube 1
10 015910 3/8 inch NPT X 5/16 inch tube 1
11 015906 Dual connection: 1/8 inch NPT X 1/4 inch tube 1
12 015908 Elbow: 1/4 inch NPT X 3/8 inch tube 1
Threaded adapters with thread sealant applied
13 015103 1/4 inch NPT X RH ‘B’ inert female 3
14 015012 1/4 inch NPT X #6 male 3
15 015009 1/4 inch NPT X RH ‘B’ male 1
16 015922 1/4 inch X hexagonal collar 5
17 015230 1/4 inch NPT X LH ‘B’ 1
18 015116 1/8 inch NPT X RH ‘A’ 1
19 015210 1/8 inch NPT X LH ‘A’ 1
20 015197 1/8 inch NPT X #5 1
