Hypertherm XPR300 Replacement Part Procedures

Parts List
5
XPR300 Instruction Manual 809970 147
Mild steel consumable starter kit with torch (428618)
Part number Description Quantity
420221 Quick-disconnect torch head 1
420240 Electrode: 80 A 2
420243 Nozzle: 80 A 2
420246 Shield: 80 A 2
420242 Swirl ring: 80 A – 130 A 2
420249 Electrode: 130 A 3
420252 Nozzle: 130 A 3
420255 Shield: 130 A 2
420261 Nozzle: 170 A 3
420258 Electrode: 170 A 3
420513 Shield: 170 A 2
420260 Swirl ring: 170 A 1
420276 Electrode: 300 A 3
420279 Nozzle: 300 A 3
420491 Shield: 300 A 2
420406 Swirl ring: 300 A 1
420368 Water tube 2
420200 Shield retaining cap 2
420365 Nozzle retaining cap 2
104879 2.25 inch spanner wrench 1
104119 Consumable tool 1
027055 Silicone lubricant, 1/4 ounce 1
