Plasma Power Supply
1
14
80
9
9
7
0
Field Service Bulletin
XPR30
0
Install the magnetics fans
1.
Put the fan on the bracket as shown.
2.
Use a 4
mm, hexa
gonal-socket wrenc
h to inst
all the 3
nuts
to att
ach the new magnetics fan to the brac
ket.
3.
Put the bottom of the fan and bracket assembly into the
sheet met
al t
ab.
4.
Connect the fan wire con
nector
.
5.
Use a 1
0
mm, hex
agonal-socket wrench to install the nut.
6.
Insta
ll the front panel.
13
15
