Hypertherm XPR300 Replacement Part Procedures

Parts List
5
146 809970 Instruction Manual XPR300
Stainless steel and aluminum consumable starter kit (428617)
Part number Description Quantity
420288 Nozzle: 40 A 3
420291 Shield: 40 A 2
420297 Nozzle: 60 A 1
420296 Nozzle: 60 A H
2
O 1
420306 Nozzle: 80 A 2
420290 Nozzle: 80 A H
2
O 2
420469 Shield: 130 A H
2
O1
420356 Electrode: 130 A – 300 A 4
420315 Nozzle: 130 A 2
420318 Shield: 130 A 1
420472 Shield: 170 A H
2
O1
420324 Nozzle: 170 A 3
420327 Shield: 170 A 1
420358 Swirl ring: 300 A fuel 1
420475 Shield: 300 A H
2
O1
420359 Nozzle: 300 A 2
420362 Shield: 300 A 2
420303 Electrode: 40 A – 80 A 3
420309 Shield: 60 A – 80 A 2
420294 Electrode: 40 A – 80 A aluminum air/air 1
420300 Shield: 60 A – 80 A H
2
O1
420314 Swirl ring: 40 A – 170 A multiple processes 1
420323 Swirl ring: 60 A – 300 A multiple processes 1
420368 Water tube 1
420200 Shield retaining cap 1
420365 Nozzle retaining cap 1
104879 2.25 inch spanner wrench 1
104119 Consumable tool 1
027055 Silicone lubricant, 1/4 ounce 1

Hypertherm XPR300 Specifications

General

Cutting Current	300 A
Duty Cycle	100% at 300 A
Technology	X-Definition Plasma
Gas Supply	Oxygen, Nitrogen, Air
Cutting Capacity (Mild Steel)	38 mm (1.5 in)
Severance Capacity (Mild Steel)	75 mm (3 in)
Pierce Capacity (Mild Steel)	50 mm (2 in)
Input Voltage	200–480 V, 3-PH, 50/60 Hz
