Table 15. MAP 0190: Forms Feed Problems (continued)
Step Questions/Actions Yes No
26.
A paper presence sensor failure can cause a ’02’ or
’099’ forms jam message to display after a Park or Eject
operation.
Did a Park or Eject operation cause the error
message?
Run T&D21, including performing
a sensor tune, and verify correct
sensor operation. If not OK:
v Install a new logic board. For
Model A00, see “Logic Board -
Model A00” on page 370. For
Models 001 and 002, see
“Logic Board - Models 001
and 002” on page 378. Or
“Logic Board - Model 003” on
page 366.
v If the printer is still failing after
the logic board has been
changed, install a new sensor
assembly cable. Go to “Sensor
Cable Assembly” on page 441.
Run T&D in automatic mode to
verify correct printer operation.
For Model A00, see “How To Run
the Test and Diagnostic (T&D)
Programs” on page 161. For
Models 001, 002, or 003, see
“How To Run the Test and
Diagnostic (T&D) Programs” on
page 201.
Go to step 27 on page 119.
Chapter 1. Diagnosing Problems
118
