Table 18. Error Messages for Models 001, 002, and 003 (continued)
Message Description Action
070 PRINTER BOARD CHANGED
VERIFY CONFIGURATION SETTINGS
Occurs when printer logic board or
microcode version has been replaced.
Verify printer configuration settings and
Custom Sets.
087 STACKER ERROR
INSTALL STACKER
The printer has failed to sense that an ASF
stacker is installed.
1. Power off the printer.
2. Ensure that the stacker is installed
correctly.
3. Power on the printer.
4. See “MAP 0170: ASF Stacker” on
page 94.
088 INVALID PAPER SOURCE
USE MANUAL OR CHANGE
CONFIGURATION
Printer requires a paper source not
installed.
1. Change configuration to match the
paper source requested (see
IBM 4247
Printer Models 001, 002 User’s Guide
,
SA24-4408).
2. Go to “MAP 0190: Form Feed
Problems” on page 101.
089 RIBBON JAM
CHECK RIBBON
The ribbon motion sensor has detected an
error.
Power off and on. If message remains, see
“MAP 0160: Ribbon Feed and Ribbon Lift”
on page 89.
096 COVER OPEN
False Message
The cover open sensor has detected an
error.
See “MAP 0180: Top Cover Interlock” on
page 98.
097 FUNCTION NOT AVAILABLE
MENU LOCKED
The Operator Panel has been locked. This
means the Configuration Menu and Printer
Adjustments functions in the Test Menu
cannot be used.
Use the procedure in “Unlocking and
Locking Printer Configuration Menu” on
page 499:
v If you need to use these functions.
v If the customer had the operator panel
locked. Always lock the operator panel
after completing your service procedures
by performing this procedure.
Chapter 1. Diagnosing Problems
142
