The print test will print, and the following message displays:
T&D 14 USER
2. When the print test is complete, the following message is displayed:
TEAR & PRESS KEY
3. Tear off the printout, and press any key.
4. For printout analysis, see “Print Quality Checks” on page 338.
5. If an error message is displayed, go to “T&D Error Messages and Actions” on page 190.
6. The test completed successfully if the display advances to the next test number.
T&D15 - First Printing Line Adjustment Test
This test allows you to adjust the first print-line for the front fanfold forms path and the rear fanfold forms path
from the operator panel.
The value set by this test becomes the first print-line position when the configuration menu item Vertical
Adjustment is set to 0.
Note: If you adjust this value, you also must run T&D17
If the following message displays, go to “T&D11 - Pinch Roller Status/Sensor Tuning/Ribbon Feed and Lift Motors”
on page 168.
PINCH XXXXX
Note: XXXXX is CLOSE or OPEN.
Return here after the sensors are tuned.
Continue with the next step when the printer displays:
YES F.FR ADJ? NO
Chapter 2. Diagnostics
175
