Note: F.FR ADJ is First print-line FRont tractor ADJustment
Front Fanfold Forms Path - To select the test for the front fanfold first-line adjustment, press the Micro ↑ key,
then go to step 1.
-or-
Rear Fanfold Forms Path - To advance to the rear, fanfold first-line adjustment, press the Load/Form Feed key.
Go to step 10 on page 177.
LOAD PAPER
1. Install fanfold paper in the front tractor assembly.
2. Press the Micro ↑ key.
3. The following message will display:
+ F.FR XXX -
4. A block of Es will be printed on the first print-line. The paper will feed to a position for viewing. Note the
position of the first print-line on the paper. The Es should be completely on the paper. The top of the Es
should be approximately 1 mm (0.04 in.) below the perforation.
5. The following message will display:
PRESS A KEY
6. Press any key to feed the paper back into the printer. The following message will display :
YES<- STORE ->NO
If the first print-line adjustment is correct, press the Micro ↑ key to store the first print-line position. Continue with
step 9.
-or-
Chapter 2. Diagnostics 176
