2. To advance to the rear, fanfold first-line adjustment, press the Load/Form Feed key. See step 11 on
page 183 .
LOAD PAPER
3. Install fanfold paper in the front tractor assembly.
4. Press the Load/Form Feed key.
5. A row of Xs will be printed on the first print-line. The paper will feed to the tear-off area.
The Xs should be completely on the paper. The top of the Xs should be approximately 1 mm (0.04 in.)
below the perforation. If this condition does not exist, perform “T&D15 - First Printing Line Adjustment
Test” on page 175, and return here.
6. The following message will display:
+ T.FR XXX -
Note: XXX can be any number between -128 and +127.
7. Figure 16 on page 182 shows the correct position of the perforation for a clean tear-off.
Chapter 2. Diagnostics 181
