19. If an error message is displayed, go to “T&D Error Messages and Actions” on page 190.
20. The test completed successfully if the display advances to the next test number.
T&D18 - Single Sheet Feed Printout
Use this test to check manual sheet paper feed and line skew.
If the test completes successfully, the display advances to the next test number.
-or-
If the following message displays, go to “T&D11 - Pinch Roller Status/Sensor Tuning/Ribbon Feed and Lift Motors”
on page 168.
Display:
PINCH XXXXX
Note: XXXXX is CLOSE or OPEN.
Return here after the sensors are tuned.
If the following messages appear in the display, continue with this procedure. These 2 messages display
sequentially:
T&D 18 USER
INSERT CUT SHEET
1. Insert a single sheet of forms [at least 356 mm (14 in.) wide] on the manual sheet feed tray.
2. During the printing, the following message will be displayed:
T&D 18 USER
3. For printout analysis, see “Manual Sheet Feed Printout” on page 343.
4. If an error message is displayed, go to “T&D Error Messages and Actions” on page 190.
5. When the print test is complete, the display advances to the next test number.
Chapter 2. Diagnostics 184
