IBM 4247 User Manual

Table 28. T&D Error Messages and Actions (continued)
Error Message Description Action
TD (**) FRU 3 14 AFTA Failure 1. See “Standard AFTA Service Check and
Adjustment” on page 285.
2. Replace the logic board. See “Logic Board - Models
001 and 002” on page 378. For Model 003, see
“Logic Board - Model 003” on page 366.
3. Replace the AFTA motor assembly. See “Automatic
Forms Thickness Adjust (AFTA) Assembly” on
page 407.
TD (**) FRU 3 15 AFTA Failure 1. See “Standard AFTA Service Check and
Adjustment” on page 285.
2. Replace the logic board. See “Logic Board - Models
001 and 002” on page 378. For Model 003, see
“Logic Board - Model 003” on page 366.
3. Replace the AFTA motor assembly. See “Automatic
Forms Thickness Adjust (AFTA) Assembly” on
page 407.
TD (**) FRU 3 16 Front Tractor Sense
Failure
1. Clear front feed paper jam.
2. See “Tractor Assembly Service Check” on
page 325.
3. Replace the logic board. See “Logic Board - Models
001 and 002” on page 378. For Model 003, see
“Logic Board - Model 003” on page 366.
4. Replace the tractor cable assembly.
TD (**) FRU 3 17 Rear Tractor Sense
Failure
1. Clear rear feed paper jam.
2. See “Tractor Assembly Service Check” on
page 325.
3. Replace the logic board. See “Logic Board - Models
001 and 002” on page 378. For Model 003, see
“Logic Board - Model 003” on page 366.
4. Replace the tractor cable assembly.
Chapter 2. Diagnostics
234
