IBM 4247

Table 2. MAP 0110: Automatic Sheet Feeder (continued)
Step Questions/Actions Yes No
2.
Check for paper or debris in the path.
Do forms feed into the stacker
without jamming?
The ’02’ or ’099’ display message is
false.
a. Run T&D11 to tune the sensors.
For Model A00, see “Test and
Diagnostic Information - Model
A00” on page 160. For Models
001, 002, or 003, see “How To
Run the Test and Diagnostic (T&D)
Programs” on page 201.
b. Run T&D21 and verify correct
sensor operation. If not OK:
1) Install a new logic board. For
Model A00, see “Logic Board -
Model A00” on page 370. For
Models 001 or 002, see “Logic
Board - Models 001 and 002”
on page 378. For Model 003,
see “Logic Board - Model 003”
on page 366.
—or—
2) Install a new sensor cable
assembly.
c. Run T&D in automatic mode to
verify correct printer operation, For
Model A00, see “Test and
Diagnostic Information - Model
A00” on page 160. For Models
001, 002, or 003, see “How To
Run the Test and Diagnostic (T&D)
Programs” on page 201.
Go to step 3 on page 30.
Chapter 1. Diagnosing Problems
29
