Table 2. MAP 0110: Automatic Sheet Feeder (continued)
Step Questions/Actions Yes No
3.
Are you here because Bin 2 or Bin
3 failed to feed paper?
Go to step 4. Go to step 5.
4. a. Swap the bad bin connector with
the Bin 1 connector. See Figure 75
on page 322.
b. From the operator panel, load
paper from Bin 1. This will cause
paper to be fed from the bad bin.
Does paper load from the bad bin
OK?
Go to step 8. Install a new bin.
Run T&D in automatic mode to verify correct
printer operation. For Model A00, see “How
To Run the Test and Diagnostic (T&D)
Programs” on page 161. For Models 001,
002, or 003, see “How To Run the Test and
Diagnostic (T&D) Programs” on page 201.
5.
Perform the main paper drive service
check. See “Main Paper Drive Check
and Adjustment” on page 301.
Is the main paper drive service
check OK?
Go to step 6. Repair as needed.
Run T&D in automatic mode to verify correct
printer operation. For Model A00, see “How
To Run the Test and Diagnostic (T&D)
Programs” on page 161. For Models 001,
002, or 003, see “How To Run the Test and
Diagnostic (T&D) Programs” on page 201.
6.
Perform the ASF service check. See
“Automatic Sheet Feeder (ASF) Bins
Service Check” on page 319
Is the ASF service check OK?
Go to step 7. Repair as needed.
Run T&D in automatic mode to verify correct
printer operation. For Model A00, see “How
To Run the Test and Diagnostic (T&D)
Programs” on page 161. For Models 001,
002, or 003, see “How To Run the Test and
Diagnostic (T&D) Programs” on page 201.
7.
Are you here due to a ’02’, or ’099’
display message?
Continue with “MAP 0170: ASF
Stacker” on page 94.
Go to step 8 on page 31.
Chapter 1. Diagnosing Problems
30
