Table 2. MAP 0110: Automatic Sheet Feeder (continued)
Step Questions/Actions Yes No
8.
Do you have the stacker/ASF
loop-back connector (PN 08H7271)?
Go to step 9. Install a new logic board. For Model 003,
see “Logic Board - Model 003” on page 366.
For Model A00, see “Logic Board - Model
A00” on page 370. For Models 001, and 002,
see “Logic Board - Models 001 and 002” on
page 378.
-or-
Install a new Stacker assembly. See
“Automatic Sheet Feeder (ASF) Bins Service
Check” on page 319.
-or-
Install a new ASF Bin 1 assembly.
-or-
Install a new stacker cable.
Run T&D in automatic mode to verify correct
printer operation. For Model A00, see “How
To Run the Test and Diagnostic (T&D)
Programs” on page 161. For Models 001,
002, or 003, see “How To Run the Test and
Diagnostic (T&D) Programs” on page 201.
