Table 2. MAP 0110: Automatic Sheet Feeder (continued)
Step Questions/Actions Yes No
9.
Run T&D10 in Single Test Mode to
test the stacker/ASF. For Model A00,
see “How To Run the Test and
Diagnostic (T&D) Programs” on
page 161. For Models 001, 002, or
003, see “How To Run the Test and
Diagnostic (T&D) Programs” on
page 201.
Did T&D10 Test run without errors?
Install a new ASF bin 1 assembly.
—or—
Install a new stacker assembly.
Run T&D in automatic mode to verify
correct printer operation, For Model
A00, see “Test and Diagnostic
Information - Model A00” on page 160.
For Models 001, 002, or 003, see
“How To Run the Test and Diagnostic
(T&D) Programs” on page 201.
Install a new logic board. For Model A00,
see “Logic Board - Model A00” on page 370.
For Models 001 or 002, see “Logic Board -
Models 001 and 002” on page 378. Or “Logic
Board - Model 003” on page 366.
-or-
Install a new stacker cable.
Run T&D in automatic mode to verify correct
printer operation. For Model A00, see “How
To Run the Test and Diagnostic (T&D)
Programs” on page 161. For Models 001,
002, or 003, see “How To Run the Test and
Diagnostic (T&D) Programs” on page 201.
