CAUTION:
Isopropyl Alcohol is flammable. Avoid sparks and open flame.
v Upper feed rollers
v Platen
v Lower plastic shield
v Paper bail rollers
v Upper plastic shield
9. Use a lint-free cloth to clean the tractor assembly jam sensor.
10. If a problem still exists, continue with the next section.
Individual Forms Paths Checks
Use the chart below to select a specific area to check for jams or failure-to-feed problems.
Table 48. Forms Path Service Checks
Paths See:
Front Push Path Page 310
Rear Pull Path Page 311
Front Push-Pull Path Page 313
Rear Push Path Page 315
Manual Sheet Path Page 317
ASF Page 319
ASF Stacker Page 322
Front Push Path Check:
Chapter 5. Removals and Adjustments 310
