4. Remove the 2 AFTA motor screws and remove the motor.
AFTA
Motor
Figure 139. AFTA Motor Connector - Model A00 Early-Level
AFTA
Motor
Figure 140. AFTA Motor Connector - Model A00 Late-Level and Models 001, 002, and 003.
Models 001 and 003
have connectors A and B. Model 002 has only connector B.
Chapter 5. Removals and Adjustments 408
