5. If the platen pinch roller gear is blocking the AFTA indicator screw, rotate the gear counterclockwise.
6. Remove the 2 AFTA indicator mounting screws and remove the indicator.
AFTA Motor
Screws
Figure 141. AFTA Motor Screws.
(Viewed From Left Side)
Platen Pinch
Roller Gear
AFTA
Indicator
Screw
Figure 142. Platen Pinch Roller Gear.
(Viewed From Left Side)
Chapter 5. Removals and Adjustments 409
