7. Remove the retaining clip and the intermediate gear.
8. Remove the screw and the carriage shaft gear.
AFTA
Indicator
Screws
Figure 143. AFTA Indicator Screws.
(Viewed From Left Side)
C-Clip
Intermediate
Gear
Figure 144. Intermediate Gear Retaining Clip.
(Viewed From Left Side)
Chapter 5. Removals and Adjustments 410
