Installation
1. Refer to Table 54 for the correct positions of the paper bail and the forms guide.
Table 54. Forms Guide and Paper Bail Positions
Selected Paper Path Forms Guide
Metal Deflector
Paper Bail
Front Push Open Closed
Manual Sheet Feed Open Closed
Rear Push Open Closed
ASF Open Closed
Rear Pull Closed Removed
Front Push-Pull Closed Closed
2. Move the printhead to the far right.
3. Grasp the paper bail, as shown in Figure 158.
Important
To avoid damaging the plastic strip, ensure the plastic strip points down.
4. Insert the left and right paper bail end caps, and pivot the paper bail down into the side frames.
Chapter 5. Removals and Adjustments 424
