IBM 4247 User Manual

Asm–
Index
Part
Number Units Description
4–1 NP Mechanical Assembly
–2 NP v Frame, Right Side
–3 NP v Frame, Left Side
–4 NP v Frame Part
–5 63H6002 1 v Frame, Manual Sheet Feed Tray
–6 08H7277 1 v Roller Assembly, Lower Feed
–7 24H7730 1 v Lower Plastic Shield Assembly (Includes 24H7729, Asm Index 4-51)
–8 1 v Bushing (PP 08H7351)
–9 1 v Clip, Retaining (PP 63H6001)
–10 08H7279 1 v Pulley, Lower Feed Roller
–11 3 v Sensor, Paper Presence (Order Sensor Cable Assembly PN 08H7251)
–12 2 v Sensor, Printhead Home and Ribbon Motion (Order Sensor Cable Assembly PN 08H7251)
–13 12 v Screw (PP 08H7356)
–14 1 v Screw, M3x6 (PP 08H7355)
–15 4 v Screw, M3x4 (PP 08H7355)
–16 63H6000 1 v Shaft, Platen Pinch Roller
–17 2 v Bushing (PP 08H7351)
–18 1 v Clip, Retaining (PP 63H6001)
–19 08H7251 1 v Cable Assembly, Sensor
–21 1 v Screw (PP 08H7355)
–22 1 v Spacer (PP 08H7353)
–23 1 v Screw (PP 08H7355)
–24 1 v Plate, Sensor (PP 08H7352)
–25 1 v Screw (PP 08H7355)
–26 08H7284 5 v Roller Assembly, Platen Pinch (Packaged 5 Per Pack)
–27 08H7285 1 v Support (Packaged 5 Per Pack)
–28 63H6272 1 v Platen Assembly
–29 08H7287 1 v Belt, Platen (Packaged 5 Per Pack)
–30 2 v Retainer, Bearing (PP 08H7352)
–31 1 v Bearing (PP 08H7351)
–32 6 v Mount, Rubber (PP 08H7352)
–33 08H7288 1 v Pulley (Packaged 5 Per Pack)
–34 1 v Screw, M3x8 (PP 08H7355)
Assembly 4: (continued)
Chapter 6. Parts Catalog 468
