IBM 4247 User Manual

Asm–
Index
Part
Number Units Description
–35 08H7289 1 v Motor, Paper Feed
–36 2 v Screw, M3x10 (PP 08H7355)
–37 1 v Washer (PP 63H6001)
–38 08H7297 1 v Frame Part
–39 4 v Support, Printhead Home/Ribbon Motion Sensor (PP 08H7353)
–40 1 v Bushing, Rubber (PP 08H7352)
–41 4 v Spacer (PP 08H7352)
–42 4 v Screw (PP 08H7356)
–43 2 v Screw (PP 08H7356)
–44 1 v Screw (PP 08H7355)
–45 08H7298 1 v Frame Part
–46 08H7290 1 v Roller Assembly, Upper Feed
–47 3 v Washer, Thrust (PP 63H6001)
–48 1 v Bushing (PP 08H7351)
–49 1 v Retainer, Cable (PP 08H7352)
–50 08H7291 4 v Roller, Lower Feed Roller Shaft Pinch (Packaged 5 Per Pack)
–51 24H7729 1 v Shield, Lower Plastic (Replaceable) (For use with 24H7730, Asm Index 4-7)
–51A 08H7355 2 v Screw, M3x4
Assembly 4: (continued)
Chapter 6. Parts Catalog 469
