Asm–
Index
Part
Number Units Description
5–1 NP Mechanical Assembly
–2 1 v Clip, Retaining (PP 63H6001)
–3 08H7299 1 v Bellcrank
–4 08H7354 1 v Mask and Adhesive, Printhead
–5 1 v Spring (PP 08H7351)
–6 08H7300 1 v Gear (Packaged 10 Per Pack)
–7 1 v Spacer (PP 63H6001)
–8 08H7301 1 v Gear, Front Tractor Idler (Packaged 10 Per Pack)
–9 1 v Clip, Retaining (PP 63H6001)
–10 08H7311 1 v Lever, Paper Feed Belt Tension
–11 08H7302 1 v Idler (Packaged 5 Per Pack)
–12 1 v Clip, Retaining (PP 63H6001)
–13 2 v Screw, M4x6 (PP 08H7355)
–14 63H6205 1 v Carriage Assembly
–15 08H7304 1 v Belt, Carriage (Packaged 5 Per Pack)
–16 1 v Belt Bracket (PP 08H7353)
–17 1 v Screw (PP 08H7356)
–18 63H6274 1 v Shaft, Carriage Support (includes eccentric bushing and screw) [old version is darker (nickel)
plating, new version is lighter (chrome) w/eccentric bushing on right]
–18A 1 vvEccentric Bushing (Part of 63H6274)
–18B 1 vvScrew (Part of 63H6274)
–19 4 v Washer (PP 63H6001)
–20 2 v Screw, M4x8 (PP 08H7355)
–21 63H6063 1 v Shaft, Carriage
–22 2 v Retainer, Carriage Shaft (PP 08H7352)
–23 1 v Bushing, Carriage Support Shaft (PP 08H7351)
–24 08H7314 1 v Screw, Carriage Belt Adjusting (Packaged 5 Per Pack)
–25 08H7315 1 v Bracket (Packaged 5 Per Pack)
–26 08H7305 1 v Pulley (Packaged 3 Per Pack)
–27 1 v Pivot (PP 08H7351)
–28 2 v Spacer (PP 08H7353)
–29 NP v Bracket, Carriage Motor
–30 4 v Grommet, Rubber (PP 08H7352)
Assembly 5: (continued)
Chapter 6. Parts Catalog 471
