Asm–
Index
Part
Number Units Description
–31 4 v Stud (PP 08H7352)
–32 08H7306 1 v Motor, Carriage
–33 2 v Screw, M4x6 (PP 08H7355)
–34 08H7307 1 v Belt, Paper Feed Drive (Packaged 5 Per Pack)
–35 08H7308 1 v Gear, AFTA Sector
–36 1 v Screw, M3x6 (PP 08H7355)
–37 2 v Clip, Retaining (PP 63H6001)
–38 4 v Screw (PP 08H7355)
–39 08H7309 1 v Gear
–40 1 v Clip, Retaining (PP 63H6001)
–41 2 v Spring (PP 08H7351)
–42 2 v Guide, Spring (PP 08H7352)
–43 08H7310 2 v Gear (Packaged 5 Per Pack)
–44 1 v Slide (PP 08H7353)
–45 2 v Washer (PP 63H6001)
–46 08H7317 2 v Bracket , Ground (Packaged 5 Per Pack)
–48 08H7359 1 v Motor, Ribbon Lift
–49 1 v Nut, M5 (PP 63H6001)
–50 08H7330 1 v Bracket, Carriage Motor Stiffening
–51 2 v Wear Surface, Sheetmetal (PP 08H7351)
Assembly 5: (continued)
Chapter 6. Parts Catalog 472
