Table 6. MAP 0121: Attachment, Models 001, 002, or 003 (continued)
Step Questions/Actions Yes No
18.
Are you here because of a T&D 30–38 failure, a ’015’,
’017’, ’027’, ’028’ error, OR no print from host OR wrong
printed character.
Replace the attachment
card. See “Model 003
Attachment Cards: Serial,
Twinax, LAN, Coax” on
page 359
– or –Install a new logic
board. See “Logic Board -
Models 001 and 002” on
page 378.
– Or –“Logic Board -
Model 003” on page 366.
Run T&D in Automatic
Mode to verify correct
printer operation. See
“How To Run the Test
and Diagnostic (T&D)
Programs” on page 201.
Verify the symptom and return to
“MAP 0100: START OF CALL” on
page 23.
Chapter 1. Diagnosing Problems
49
