Table 9. MAP 0131: Paper Path Sensor (continued)
Step Questions/Actions Yes No
5.
Is the current forms path either rear pull or
push-pull?
Run T&D21 and verify correct
sensor operation. If not OK:
v Install a new logic board. For
Model A00, see “Logic Board
- Model A00” on page 370.
For Models 001 and 002, see
“Logic Board - Models 001
and 002” on page 378. Or
“Logic Board - Model 003” on
page 366.
-or-
v Install a new sensor cable.
See “Sensor Cable Assembly”
on page 441.
Run T&D in automatic mode to
verify correct printer operation.
For Model A00, see “How To
Run the Test and Diagnostic
(T&D) Programs” on page 161.
For Models 001, 002, or 003,
see “How To Run the Test and
Diagnostic (T&D) Programs” on
page 201.
Go to step 6 on page 69.
