Table 11. MAP 0150: Power Supply (continued)
Questions/Actions Yes No
15. a. Power off (O) the printer.
b. Connect the AFTA motor connector.
c. Power on (|) the printer.
Does the power supply fan run OK?
Go to step 16. Power off (O) the printer.
Install a new AFTA motor. See
“Automatic Forms Thickness Adjust
(AFTA) Assembly” on page 407.
Run T&D in automatic mode to verify
correct printer operation. For Model
A00, see “How To Run the Test and
Diagnostic (T&D) Programs” on
page 161. For Models 001, 002, or 003,
see “How To Run the Test and
Diagnostic (T&D) Programs” on
page 201.
16. a. Power off (O) the printer.
b. Connect the paper feed motor connector.
c. Power on (|) the printer.
Does the power supply fan run OK?
Go to step 17 on page 86. Power off (O) the printer.
Install a new paper feed motor. See
“Paper Feed Motor” on page 447.
Run T&D in automatic mode to verify
correct printer operation. For Model
A00, see “How To Run the Test and
Diagnostic (T&D) Programs” on
page 161. For Models 001, 002, or 003,
see “How To Run the Test and
Diagnostic (T&D) Programs” on
page 201.
Chapter 1. Diagnosing Problems
85
