21.1 Planning for the installation
Proper planning is always a crucial step in every configuration, and here we list some
important considerations:
򐂰 AIX host attachment to the DS3500 storage subsystems requires the additional purchase
of the AIX operating system Host Kit Option or Feature Code. The AIX Host Kit options
contain the required IBM licensing to attach an IBM AIX Host System to the DS3500.
Contact your IBM service representative or IBM reseller for purchasing information.
򐂰 Multiple combinations of servers, AIX versions, Host Bus Adapters (HBA’s), firmware
levels and multipath drivers can be used in order to connect a POWER system to a
DS3500 storage subsystem. For detailed HBA and systems information regarding
combinations, see the following Web site to access the System Storage Interoperation
Center (SSIC):
http://www.ibm.com/systems/support/storage/config/ssic
The SSIC can provide the interoperability matrix, and is a selection driven tool where you
provide the criteria for your configuration.
To verify the microcode level on the HBA’s use the following commands:
– lscfg -vl fcs0 (The Z9 or ZA fields contains the firmware level)
– lsmcode -d -d fcs0
– fcstat fcs0
򐂰 To be able to map the logical drive to the host and to configure the zoning, it is necessary
to get the WWN of each HBA port (fcsX). The Example 21-1 shows how to get the WWN
in VIOS and the Example 21-2 shows how to get it on AIX.
Example 21-1 WWN from VIOS
$ lsdev -dev fcs0 -vpd
fcs0 U78A5.001.WIH1752-P1-C10-T1 FC Adapter
Network Address.............2100001B3208E0AB
ROS Level and ID............49535020
Device Specific.(Z0)........0004001B
Device Specific.(Z1)........02040083
Device Specific.(Z2)........49535020
Device Specific.(Z3)........00002422
Device Specific.(Z4)........000E0002
Device Specific.(Z5)........00010009
Device Specific.(Z6)........00010002
Device Specific.(Z7)........00000000
Device Specific.(Z8)........2100001B3208E0AB
Device Specific.(Z9)........ISP
Hardware Location Code......U78A5.001.WIH1752-P1-C10-T1
PLATFORM SPECIFIC
Name: fibre-channel
Model: QMI2472
Node: fibre-channel@1
Device Type: fcp
