AIX.fm Draft Document for Review March 28, 2011 12:24 pm
650 IBM System Storage DS3500: Introduction and Implementation Guide
q_type simple Queuing TYPE True
queue_depth 10 Queue DEPTH True
reassign_to 120 REASSIGN time out value True
reserve_policy no_reserve Reserve Policy True
rw_timeout 30 READ/WRITE time out value True
scsi_id 0x680000 SCSI ID False
start_timeout 60 START unit time out value True
ww_name 0x20480080e51b0c90 FC World Wide Name False
21.2 Configuring MPIO
The following parameters need to be changed when using MPIO with physical devices:
򐂰 Change the fc_err_recov attribute to fast_fail and dyntrk attribute to yes on all the Fibre
Channel adapters. It is possible to use the lsdev -type adapter command to find the
number of the Fibre Channel adapter. Use the chdev command, as shown in
Example 21-6 and Example 21-7 to change the attributes.
Example 21-6 Changing the attributes on VIOS
$ chdev -dev fscsi0 -attr fc_err_recov=fast_fail dyntrk=yes -perm
fscsi0 changed
$ lsdev -dev fscsi0 -attr
attribute value description
user_settable
attach switch How this adapter is CONNECTED False
dyntrk yes Dynamic Tracking of FC Devices True
fc_err_recov fast_fail FC Fabric Event Error RECOVERY Policy True
scsi_id 0x660c00 Adapter SCSI ID False
sw_fc_class 3 FC Class for Fabric True
Example 21-7 Changing the attributes on AIX
# chdev -l fscsi0 -a fc_err_recov=fast_fail -a dyntrk=yes -P
fscsi0 changed
It is very important to change these two parameters. The reason for this is the following:
– Dyntrk: The default for this setting is “no”. When set to “yes” it will enable dynamic
tracking of FC devices, and the FC adapter driver detects when the Fibre Channel
N_Port ID of a device changes. The FC adapter driver then reroutes traffic destined for
that device to the new address while the devices are still online. Events that can cause
an N_Port ID to change include moving a cable between a switch and storage device
from one switch port to another, connecting two separate switches using an
inter-switch link (ISL), and possibly rebooting a switch.
– fc_err_recov: This parameter controllers the fast I/O failure and is useful in situations
where multipathing software is used. Setting the fc_err_recov attribute to fast_fail can
decrease the I/O fail times because of link loss between the storage device and switch.
This technique supports faster failover to alternate paths when FC adapter driver
detects a link event, such as a lost link between a storage device and a switch. The FC
Important: Because this attributes cannot be changed while the device is in active state,
the -perm flag for VIOS and -P for AIX is used so that the change is made in the ODM only.
The changes are applied to the device when the system is rebooted.
