17: U
SER
C
OMMUNICATION
I
NSTRUCTIONS
17-24
O
PEN
N
ET
C
ONTROLLER
U
SER
’
S
M
ANUAL
8.
In the Receiv
e instruction dialog box, type
M20
in the destination D1 box and type
D200
in the destination D2 box.
When finished, click
OK
.
Programming of the RXD1 instruction is complete and the recei
ve data will be stored as follo
ws:
5678h
D20
90ABh
D21
= 22136
= 37035
